Smartphone
Amplifier
Guitar
EXP INPUT OUTPUT
AUX IN PHONES USB OTG
9V 300mA
Smartphone / audio device
Headphones
Computer
Expression Pedal
1. Make the desired connection between the guitar and the equipment.
2. Connect the supplied power adapter to the power supply input of the device and then
plug the power adapter into an AC outlet.
Connection options
Connection to the power supply
Installation
12
DNAfx GiT Core
Multi Eects Unit
