Amplifier
Guitar
EXP INPUT OUTPUT
AUX IN PHONES USB OTG
9V 300mA
1. Connect the guitar to the [INPUT] socket of the device.
Turn o the [AMP] and [CAB] eects.
2. Connect the input of the amplier to the output jack [OUTPUT] of the unit.
Connection to the input socket
of the amplier
Installation
DNAfx GiT Core
13
Multi Eects Unit
