Power amplifier
Guitar
EXP INPUT OUTPUT
AUX IN PHONES USB OTG
9V 300mA
1. Connect the guitar to the [INPUT] socket of the device.
Turn o the [CAB] eect.
2. Connect the RETURN interface of the power amplier to the [OUTPUT] socket of the
device.
Connection to the power ampli‐
er
Installation
14
DNAfx GiT Core
Multi Eects Unit
