thomann Harley Benton DNAfx GiT Core - Page 15

Amplifier
Guitar
EXP INPUT OUTPUT
AUX IN PHONES USB OTG
9V 300mA
1. Connect the guitar to the input of an amplier.
Turn o the [AMP] and [CAB] eects.
2. Connect the SEND interface of the amplier to the [INPUT] socket of the device.
3. Connect the RETURN interface of the amplier to the [OUTPUT] socket of the device.
Connection to a eects looper
Installation
DNAfx GiT Core
15
Multi Eects Unit
