EXP INPUT OUTPUT
AUX IN PHONES USB OTG
9V 300mA
Guitar
Headphones
Audio device
1. Connect the guitar to the [INPUT] socket of the device.
2. Connect an audio interface to the [OUTPUT] socket of the device.
3. Connect headphones to the [PHONES] socket.
Studio
Installation
16
DNAfx GiT Core
Multi Eects Unit
