EXP INPUT OUTPUT
AUX IN PHONES USB OTG
9V 300mA
Guitar
Headphones
Mixer
1. Connect the guitar to the [INPUT] socket of the device.
2. Connect a mixer to the [OUTPUT] socket of the device.
3. Connect headphones to the [PHONES] socket.
Stage
Installation
DNAfx GiT Core
17
Multi Eects Unit
