5 Setting up the drum set
Unpack and carefully check that there is no transportation damage before using the unit. Keep the equipment packaging. To fully
protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own
packaging material suitable for transport or storage, respectively.
Establish all connections as long as the unit is switched off. Use the shortest possible high-quality cables for all connections.
Connecting pads and pedals
Connect each of the trigger inputs on the rear panel of the drum module using the supplied cables with the corresponding pad.
The snare drum is equipped with a stereo input, and thus supports double-triggering. Also for the hi-hat pedal a stereo input is
available.
Notes:
n The sound of hitting the hi-hat pad is controlled by the hi-hat pedal. Similar to a real drum kit, the hi-hat sounds ‘open‘ when
the pedal is released. If you step on the pedal the hi-hat sounds ‘closed’.
n The half of the pad on the players side is the effective striking area of a cymbal pad (ride, crash or hi-hat). In this respect
cymbal pads differ from other pads.
Setting up the drum set
e-drum set
10
