4 Installation and starting up
Connect the power supply unit to the 12 V input on the device, and then insert the power plug
into the socket-outlet.
Connect the bass drum pedal and the hi-hat controller to the corresponding inputs on the rear
of the drum module.
Connect the headphone cable to the corresponding input on the rear of the drum module.
Connect your MIDI or USB device to the USB/MIDI interface on the rear of the drum module.
Connecting the power supply
Connecting the pedals
Connecting headphones
USB/MIDI interface
Installation and starting up
mobile drum
14
