You have the option to change the MIDI note assigned to a pad. To do so proceed as follows:
1. Press [MODE] repeatedly until the LED [VOICE] lights up.
2. Hit the respective pad to activate it.
ð
The number assigned to the MIDI note appears in ‘Nxx’ format on the display.
3. Adjust the number using the buttons [–]/[+] (setting range: 0 to 99).
The setting is automatically stored.
The following table shows the MIDI mapping in default setting.
No. Name Assigned MIDI note
1 Crash 1 49
2 Tom 1 48
3 Tom 2 45
4 Tom 3 43
Adjusting assigned MIDI note
Operating
e-drum module
32
