Graphic EQ (16)
Your PM800 is equipped with a 7 band graphic EQ for the main mix. With these faders you
can boost or attenuate the selected frequency by 15 dB with a fixed bandwidth. With all
faders at centre position, the output response of the EQ is flat. The EQ function can be used,
to shape the contour of the frequency spectrum and is available, as soon as the unit is pow‐
ered up.
Output level LEDs (17)
Use these 4 LEDs to monitor the output power.
POWER indicator (18)
This LED will light up as soon as the unit is turned on.
LEVEL control (19)
This control is used to adjust the overall output level from —¥ to +10 dB.
DSP section
Your PM800 features a special 100-preset digital effects section. You will read more about
this later.
Control elements
powermixer
20
