DSP display (20)
Here the unit displays the number of the current preset.
PROGRAM control (21)
Adjust this control to select the desired effect out of 100 options available: Echo, vocal, plate,
and versatile two-effect combinations. When you are satisfied with the chosen preset, push
this knob to confirm this preset.
DSP MUTE switch (22)
Use this switch to activate or deactivate the effect section. For a more convenient operation
of this function you can connect a foot switch (not supplied) to the "FOOT SWITCH" socket
(28).
CLIP/MUTE LED (23)
This LED lights up when either the input signal is too strong, or when the DSP section is
muted.
AUX/DFX RET (24)
This control is used to adjust the volume of the effects return signal.
Control elements
PM800
21
