FX SEND (25)
Use this 1/4" jack socket to feed the signal from AUX bus to external devices like effects unit
or stage monitors.
FX RETURN (26)
This jack is used to return the signal processed by an external effects unit into the main mix.
You can also use it as an extra auxiliary input, if you're running short of "normal" input chan‐
nels.
COMP./LIM. switch and indicator (27)
Set the COMP./LIM switch to ON position, to prevent your signals from exceeding a threshold
that would cause distortion. If the input signal does not reach that threshold while this func‐
tion is activated, the indicator lights up in green. When the input signal becomes too strong
and exceeds the threshold, the indicator turns red.
FOOT SWITCH (28)
You can connect an external foot switch (not supplied) to this 1/4" socket, to turn the built-in
effects section on or off.
MONITOR OUT (29)
This socket is used to connect the input of an external monitor amp or active speakers.
Control elements
