Thomas 153 - Torque Specifications

64
153/135TA/137
Tires
Standard............................................................................................10.00 x 16.5, 6 ply rating, 40 - 45 PSI (276 - 310 kPa)
Fluid Capacities
Fuel tank ............................................................................................................16. 8 Gal. (64 L) ......................Diesel No. 2
Final drive transmissions (each) ..........................................................................1.5 gal. (5.7 L) ..................10W30 API SJ
Hydraulic reservoir ...............................................................................................8 gal. (30.3 L) ..................10W30 API SJ
Engine oil ...............................................................................................................8. 5 qts. (8 L) .................10W30 API CF
Engine cooling system ........................................................................................3. 2 gal. (12 L) ....50/50 water & ethylene
5.2 TORQUE SPECIFICATIONS
Loader
Wheel nuts (24) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 - 110 ft lbs. (136 - 139 Nm)
Chain tightener adjuster nuts (6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150 ft. lbs. (203 Nm)
Torque motor drive sprocket (2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 350 ft. lbs.(475 Nm)
Hydraulic / Hydrostatic
Gear pump section bolts (8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 - 28 ft. lbs. (34 - 38 Nm)
Piston pump section bolts (8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 - 31 ft. lbs. (37 - 42 Nm)
Torque motor section bolts (4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 ft. lbs. (68 Nm)
Hydraulic filter, case (1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30 ft. lbs. (41 Nm)
FOR NON-CRITICAL AND NOT OTHERWISE MENTIONED APPLICATIONS. THE FOLLOWING GENERAL
ASSEMBLY TORQUES WILL APPLY:
Bolts & Nuts Torque
Lbs. ft. (Nm)
1/4 - 20 5 - 7 (6. 7 - 9. 5)
5/16 - 18 12 - 15 (16 - 20)
5/16 - 24 12 - 15 (16 - 20)
3/8 - 16 17 - 22 (23 - 30)
3/8 - 24 22 - 27 (30 - 37)
7/16 - 14 30 - 35 (41 - 47)
7/16 - 20 40 - 45 (54 - 61)
1/2 - 13 45 - 50 (61 - 68)
1/2 - 20 50 - 60 (68 - 81)
9/16 - 12 60 - 70 (81 - 95)
9/16 - 18 65 - 75 (88 - 102)
5/8 - 11 75 - 85 (102 - 115)
5/8 - 18 100 - 110 (136 - 139)
5. SPECIFICATIONS
