63
Controls
VEHICLE: Steering direction and speed controlled by two hand operated control levers.
HYDRAULICS: Lift and bucket tilt are controlled by seperate foot pedals or hand controls. Auxiliary hydraulics
controlled by foot pedal.
ENGINE: Hand throttle, key type ignition switch and shutoff.
Engine 153 135TA/137
Make and model...............................................................................Kubota V2203E....................................Kubota V1903E
Cylinders .....................................................................................................4.........................................................................4
Cooling system .......................................................................................Liquid............................................................Liquid
Displacement ................................................................................134 cu.in. (2197 cc).......................113.3 cu. in. (1857 cc)
Horsepower (Gross) ...................................................................................50......................................................................42
Power (ISO 9249 Net Power) ..........................................................34.3 kW (46 Hp)....................................29 kW (39 Hp)
Power (ISO 9249 Net Power) CE..................................................33.8 kW (45.3 Hp).............................28.9 kW (38.8 Hp)
Max Torque.................................................................................115 ft. lbs. (15.9 kg/m)...................96 ft. lbs. (13.25 kg/m)
Fuel Type.......................................................................................................................Diesel No.2
Air Cleaner................................................................................................Replaceable Dry Cartridge w/Indicator
High Idle RPM..........................................................................................2800 ...............................................................2800
High Idle RPM, CE...................................................................................2600...............................................................2600
Hydraulic System
Pump type .......................................................................................................................Gear
Pump Capacity (theoretical) .........................................@ 2800 16.6 GPM (75.5 L/min).....@ 2600 15.4 GPM (70 L/min)
Control Valve.............................................................................Series type with float on lift and detent on auxiliary
Filtration..........................................................................................................................5 Micron
Hydraulic Fluid...................................................................................................10W30 API Class, SG
Oil Cooler.................................................................................................................674 BTU (711 kCal)
Cylinders. ................................................Lift (153)..........................Lift (135TA/137)..................Tilt (153/135TA/137)
Type..................................................Double acting.......................Double acting..........................Double acting
Qty- per mach .............................................2...........................................2 .............................................2
Bore dia ..................................................2.5 in......................................2 in.........................................2.5 in.
Rod dia ...................................................1.5 in....................................1.25 in....................................1.125 in.
Stroke .................................................27.125 in................................27.125 in.................................13.375 in.
Hydrostatic Transmission & Final Drive:
Pump type .................................................................................................Two in line, axial piston pumps
Pump displacement ..........................................................................................2.65 cu. in. (43.5 cm
3
)
Motor type ..................................................................................................................Geroler
Motor displacement .......................................................................................31.9 cu. in. (523.6 cm
3
)
System relief setting .........................................................................................5000 PSI (345 bar)
Final drive .......................................................................................Single roller chain running in oil bath to each axle
Drive chain size ..........................................................................................................ASA 100
Electrical 153/135TA/137
Alternator ........................................................................................................................40 A
Battery ..........................................................................................................................1 x 12V
Type (BCI GROUP).......................................................................................................34/78
Cranking Amps................................................................................................................730
Starter.......................................................................................................................12 V (1.4 kW)
Circuit breaker setting ....................................................................................................40 A
5. SPECIFICATIONS
