THOMSON 500015 - Page 16

MeasureAandB,thendeterminesideX(inmm)asinthetableabove.
Positionthearmandcheckifit’shorizontal.
MOTORISED KIT WITH ARTICULATED ARMS
FOR SINGLE OR DOUBLE LEAF SHUTTERS
EN
16
D - INSTALLATION
B
A
X
Wall
A(mm)
B(mm)
20to40 45 50 55 60 65
10 175 175 175 175 175 175
20 175 175 175 175 175 175
30 175 175 175 175 175
40 175 175 175 170
50 175
24mm
X
