MOTORISED KIT WITH ARTICULATED ARMS

FOR SINGLE OR DOUBLE LEAF SHUTTERS

D - INSTALLATION

Routethepowercable.

Wires(powersupply,antennacables)mustnotbeincontactwithanymobilepart.

3 - INSTALLATION ON LEFT-HAND SHUTTER* ONLY

*Openingtotheleftopeningseenfromtheoutside

Step 1

Markalineat3mmfromtheclosedshutteronthelintel.

Thislinewilldeterminethepositionofthegear.

Measurethelengthoflintel.

interior

lengthoflintel

PP

interior
