THOMSON 500015 - 6 - CONNECTING A WIRED CONTROL SWITCH (OPTIONAL)

25
EN
D - INSTALLATION
5 - REMOTE CONTROL
Removetapetoactivatebattery.
MOTORISED KIT WITH ARTICULATED ARMS
FOR SINGLE OR DOUBLE LEAF SHUTTERS
6 - CONNECTING A WIRED CONTROL SWITCH (OPTIONAL)
Tobeoperational,thewhitewireandtheothertwowiresmustbeincontactdependingonwhetheryou
wanttoopenorclosethedoor.
-Whiteandbluecontact:closure
-Whiteandredcontact:opening
Assoonastheyarenolongerincontact,thegearstops.
Ifalwaysincontactwhiletheshutterisfullyopenorclosed,thegearmotorwillstopbuttheradiocontrolwill
beblocked.
2 pushbuttons
1 two-stage button
1 three-stage button
Asthereisawiderangeofshutterswitches,followtheoperatingprincipleoutlinedabovetowiretheswitch
correctly.
Caution: In oder to operate the radio control, the white wire should not remain in contact with
either of the two other wires when the movement is complete.
CAUTION : Do not connect
these three wires to 230V
mains, as they carry very
low voltage signals.
1P
2P
Red
Blue
White
Gearmotor
Red
Blue
White
Gearmotor
P
1
2
Red
Blue
White
Gearmotor
P
1
3
2
