B - PRODUCT DESCRIPTION
1 - COMPOSITION OF THE KIT
1 Transmissionaxis
2 Enginemount
3 Delay(slow)left
4 Cablesleeve
5 Transmissionframe
6 Delay(fast)left
7 Anchorsø10mm
8 Anchorsø7mm
9 Lag80x8
10 Screws45x6
11 Protectivecasing
12 Bottom,right
13 Arm,left
14 BoltM12x20
15 Washer
16 Screw20x4
17 Push-buttoncover
18 Holescoverformount
19 Protectivecasing
20 Hazardtape
21 Remotecontrol
1
x1
11
x1
12
x1
13
x1
4
x1
5
x1
8
x2
10
x2
17
x2
18
x2
19
x2
20
x2
21
x1
6
x1
7
x4
9
x4
14
x4
15
x4
16
x4
2
x1
3
x1
MOTORISED KIT WITH ARTICULATED ARMS
FOR SINGLE OR DOUBLE LEAF SHUTTERS
