MOTORISED KIT WITH ARTICULATED ARMS
FOR SINGLE OR DOUBLE LEAF SHUTTERS
1 - MOTORISED SHUTTER SPECIFICATION
Inordertoinstallthemotorisation,combinesideAandsideBasshowninthegreyboxes(
)oftable
below.
SideC:distancebetweenwindowandclosedshutter=130mmminimum.
Lengthofwindow
1left-handshutter
Lengthofwindow
1right-handshutter
68cmto110cm 85cmto110cm
Exterior
85cmto140cm
Lengthofwindow2leaves
B
C
A
Window
Exterior
DistanceAinmm
DistanceB
enmm
20mmto40mm 45mm 50mm 55mm 60mm 65mm
10mm
20mm
30mm
40mm
50mm
