THOMSON 500015 - 2 - INSTALLATION ON DOUBLE LEAF SHUTTER OR ON RIGHT-HAND SHUTTER ONLY

9
EN
D - INSTALLATION
MOTORISED KIT WITH ARTICULATED ARMS
FOR SINGLE OR DOUBLE LEAF SHUTTERS
2 - INSTALLATION ON DOUBLE LEAF SHUTTER OR RIGHT SHUTTER ONLY*
*Openingtotherightseenfromtheoutside
If installation is made on right leaf only, follow steps 1 to 5 without mounting the left arm (element
no. 13).
Step 1
Markalineinsideat3mmfromtheclosedshutter,onthelintel.
Thislinewilldelimitthepositionofthegear.
Measurethelengthofthelintel.
3 mm
interior
Lengthoflintel
