Connectors
ANT IN - IEC Female
AV (3,5mm stereo jack)
S/PDIF (coaxial)
USB 2.0, Type A connector (5 V/500 mA)
HDMI
IR IN –infrared extender connector
General data
Power supply: АС 100 – 240 V ~ 50/60 Hz
Input voltage: DC 12 V, 1.0 A
Power consumption: 9.00 W max., 6.00 W typ.
Power consumption in standby: max 0.5 W
Operating temperature range: 0 °C ~ +40 °C
Storage temperature: -10 °C ~ +50 °C
Operating humidity range: 0 ~ 93% RH, non-condensing
Dimensions (W x D x H) in mm: 162 x 117 x 37
Weight in kg: 0.22
