Page #28 background imageLoading...
Page #28 background image
Compact Scientific Digital Cameras Chapter 6: CS165CU Specifications
Rev C, August 27, 2021 Page 25
6.4. Example Frame Rates (USB 3.0)
ROI
Frame Rate
Full Sensor (1440 x 1080)
34.8 fps
Half Sensor (720 x 540)
67.0 fps
1/10th Sensor (144 x 108)
260.0 fps
Min ROI (80 x 4)
>800 fps
~1 ms Exposure Time, 1 x 1 Binning, Frames per Trigger = Continuous
Frame rate is directly dependent on the capabilities of the host computer. Results may vary.
See also Section 4.3 Frame-Rate Control
6.5. CS165CU Power Consumption
1.17 W Max @ 34.8 fps Full Sensor ROI
6.6. Operating/Storage Temperatures
Operating: 10 °C to 40 °C (Non-condensing)
Storage: 0 °C to 55 °C
