Page 16 10997-D02
MAX300 Series 3-Axis Flexure Stages
4.7 Dimensions
4.7.1 Top Platform
Fig. 4.4 Dimensions – top platform
B holes M3 (6-32 UNC)
4 holes for M3
attachment screws
20
(0.79)
20
(0.79)
7.5
(0.3)
60 (2.36)
A
60
(2.36)
Product No
AMA001
AMA003
AMA005
A
28 (1.10
35 (1.38)
45 (1.77)
B
12 (0.47)
12 (0.47)
14 (0.55)
30.0 (1.18)
17.0 (0.67) 17.0 (0.67)
20.0 (0.79) 20.0 (0.79)
5.3 (0.21)
5.3 (0.21)
20.0 (0.79) 20.0 (0.79)
17.0 (0.67) 17.0 (0.67)
5.3 (0.21)
5.3 (0.21)
10.0 (0.39)
10.0 (0.39)
10.0 (0.39) 10.0 (0.39)
30.0 (1.18)
60.0 (2.36)
7.5
(0.3)
7.5
(0.3)
3 Pitches of 15.00 (0.59) = 45.0 (1.77)
3 Pitches of 15.00 (0.59) = 45.0 (1.77)
60.0 (2.36)
4.0 (0.16)
1.6 (0.06)
3.0 (0.12)
3.00 (0.12)
1.6
(0.06)
all dimensions in millimetres (inches)
