Page #21 background imageLoading...
Page #21 background image
Rev 24 Oct 2018
Page 19
Chapter 6 Specifications
Chapter 6 Specifications
6.1 Specifications
Parameter Value
Load capacity 1 kg
Travel Manual (coarse) and motor: 4 mm
Manual (fine): 300µm
Piezo: 20 micron
Resolution Manual (coarse) 0.5 mm per revolution
Manual (fine) 50 µm per revolution
Piezo (without feedback) 20 nm
Piezo (with feedback) 5 nm
Note
The resolution of a manual drive corresponds to a 0.5 degree adjustment of the
thimble; the actual resolution obtained depends on the skill of the user.
The resolutions of the piezo actuators are those typically obtained using Thorlabs
controllers.
Piezo Capacitance 3.6 µF
Top Plate Parallelism Error <100 µm
Arcuate displacement See next page
Power supply
Piezoactuated NanoMax Nominal maximum input voltage: 75 V
Stepper Motor Maximum input voltage: 24 V
Caution
The NanoMax should only be used in conjunction with the appropriate Thorlabs
Piezoelectric Controllers.
