6 Programmers Reference
15
MTD415T Data Sheet Rev. 1.0
6.2.4 Control Loop
Loop Test
Command
Explanation
Response Example
Programming
"Gx"
Sets the critical gain to x *)
Value range x: 10 to 100000 [mA/K]
Reading
"G?"
Reads the critical gain
[x<LF>][mA/K]
Command
Explanation
Response Example
Programming
"Ox"
Sets the critical period to x *)
Value range x: 100 to 100000 [msec]
Reading
"O?"
Reads the critical period
[x<LF>][msec]
PID Settings
Command
Explanation
Response Example
Programming
"Cx"
Sets the cycling time to x *)
Value range x: 1 to 1000 [msec]
Reading
"C?"
Reads the cycling time
[x<LF>][msec]
Command
Explanation
Response Example
Programming
"Px"
Sets the P Share to x *)
Value range x: 0 to 100000 [mA/K]
Reading
"P?"
Reads the P Share
[x<LF>][mA/K]
*) This set value remains during the actual power-on cycle. Use the "M" command to save it to the non-volatile
memory.
