Page #6 background imageLoading...
Page #6 background image
© 2016 Thorlabs GmbH
6
MTD415T
MTD415T Data Sheet Rev. 1.0
2 Technical Data
2.1 Absolute Maximum Ratings
Supply Input Voltage
4.5 V to 6 V
Supply Input Current
1.6 A
TEC Output Current
-1.5 A to 1.5 A
TEC Compliance Voltage
4.0 V
Maximum Output Power
6.0 W
Power Dissipation
1.5 W
Pin Voltage Range
1
)
VDD
ENABLE, RX, TEC-, TEC+
TEMP
-0.3 V to 6 V
-0.3 V to (VDD + 0.3 V)
-0.3 V to 3.3 V
Maximum Output Current STATUS, TX
10 mA
Maximum Input Current ENABLE, RX
10 mA
Operating Temperature
-40 °C to + 70 °C
1
) All voltages with respect to network ground terminal.
Notes
(1) Above specifications are given for the free-air operating temperature range unless
otherwise noted.
(2) Stresses beyond those listed above may cause permanent damage to the product. These
are stress ratings only; functional operation of the MTD415T at these or any other
conditions beyond those indicated under Recommended Operating Conditions and
Electrical Characteristics is not implied.
(3) Operation beyond the maximum rated conditions for extended periods may affect product
reliability.
2.2 Recommended Operating Conditions
Supply Voltage
Operating Temperature
6
7
