THORLABS PDA10CF - Chapter 6 Specifications

InGaAs Amplified Detector Chapter 6: Specifications
Page 8 13122-D02
Chapter 6 Specifications
All performance specifications are typical, performed at 25 °C ambient
temperature, and assume a 50  load, unless stated otherwise.
Electrical Specifications
Detector - InGaAs PIN
Active Area - Ø0.5 mm (0.2 mm
2
)
Wavelength Range  800 to 1700 nm
Peak Wavelength 
p
1590 nm (Typ)
Peak Response
( 
p
)
1.04 A/W (Typ)
Small Signal Bandwidth - 150 MHz
NEP (λ
p
) W/Hz 1.2 x 10
-11
Noise (RMS) - 1.4 mVrms
Max Ouput Current I
OUT
100 mA
Dark Offset - ±20 mV
Load Impedance - 50  to Hi-Z
Transimpedance Gain -
5 x 10
3
V/A (Hi-Z)
1 x 10
4
V/A (50 )
Output Voltage V
OUT
0 to 5 V (50 )
0 to 10 V (Hi-Z)
General
On/Off Switch Slide
Output BNC (DC Coupled)
Package Size
2.80" x 1.90" x 0.83"
(70 mm x 48 mm x 21 mm)
PD Surface Depth 0.16" (4.1 mm)
Weight, Detector Only 0.2 lbs
Accessories
SM1T1 Coupler
SM1RR Retainer Ring
Operating Temp 10 to 50 °C
Storage Temp -25 to 70 °C
AC Power Supply AC – DC Converter
Input Power
2
31 W
100 – 200 VAC (50 to 60Hz)
220 – 240 VAC (50 to 60 Hz)
2
Although the power supply is rated for 31 W the PDA10CF(-EC) actual usage is <5 W
over the full operating range.
