S2R-H80 Single & Dual Cockpit
AIRPLANE FLIGHT MANUAL
AFM H8001 SINGLE & DUAL COCKPIT Revision C Page 10
FAA APPROVAL DATE: 09/03/2015
n. LocatedbelowMVP-50Tscreen:
“USEABLE FUEL 114 U.S. GAL.PER TANK.
FUEL ABOVE 82 GAL. IS UNGAGEABLE”
o. Locate inside baggage compartment on floor near baggage compartment
doors:
“100 POUNDS MAXIMUM BAGGAGE”
p. Locate at hopper rinse port:
”HOPPER RINSE FILLER PORT”
q. Locate at external power receptacle centered on the inside of the
receptacle door.
“EXTERNAL POWER RECEPTACLE”
r. Locate at fuel filter door:
“FUEL FILTER INSPECTION”
s. Locate at smoker tank port centered on inside of filler door:
”SMOKER TANK FILLER PORT”
t. Locate above Pitot Static Buttons:
“STATIC AIR – KEEP CLEAN”
u. Located near door:
“RESTRICTED”
v. Locate on the Outside in the Center of Oil Dipstick Access Door.
“OIL”
w. Locate on the inside in the Center of Oil Dipstick Access Door.
“OIL
SEE AFM SECTION 1.1
FOR PERMISSIBLE OIL”
x. Located on center upper instrument panel:
“STABILIZED GROUND OPERATION IS PROHIBITED BETWEEN 400
AND 1100 RPM. THE PROPELLER MAY BE OPERATED WHEN
FEATHERED AT OR BELOW 400 RPM.”
y. Locate on left upper instrument panel above MVP:
“MAX ENGINE GROUND RUN TIME: 30 MINUTES”
