S2R-H80 Single & Dual Cockpit
AIRPLANE FLIGHT MANUAL
AFM H8001 SINGLE & DUAL COCKPIT Revision B Page 11
FAA APPROVAL DATE: 3/19/2015
z. Locate above main fuel filler caps:
“FUEL LEVEL INDICATOR
110 U. S. GAL
100 U. S. GAL
88 U. S. GAL
66 U. S. GAL”
aa. Locate below main fuel filler caps:
“FUEL TANKS ARE INTERCONNECTED.
ALLOW SUFFICIENT TIME FOR FUEL LEVEL
TO EQUALIZE BEFORE TOP OFF OF TANK.”
bb. Locate inside baggage compartment on floor in proximity to compartment
door latches. NOTE: 2 latches - 2 placards.
“DO NOT SLAM DOOR.
PULL LATCH TO CLOSE.
SEAT LATCHES FLUSH”
cc. Locate inside the baggage compartment and centered 1.25” from outside
edge:
“SECURE BAGGAGE TO TIE DOWN CLAMPS
TO PREVENT SHIFTING IN FLIGHT”
dd. Locate on the Right Hand Instrument Panel Above the Fuel Filter Bypass
Circuit Breaker.
FUEL FILTER.
ee. Locate on the Right Hand Instrument Panel below the Fuel Filter Bypass
Circuit Breaker.
BYPASS.
ff. Locate on the Left Hand Instrument Panel Below the Fuel Filter Bypass
Light.
FUEL FILTER BYPASS
