36
Brake pedal:
The parts making up the brake pedal spring are in the
BRAKE box. There are two springs with different
resistances:
− A1 spring (long, black): weak resistance;
− A2 spring (short, grey): strong resistance.
Set aside the spring that you do not want to use.
3. Insert all the parts of the brake pedal spring on the
metal rod in the following order: spring, washer,
buffer and support.
On the support, the UP marking must point upwards.
