Thule Slide Out G2 - Installation Guidelines; Vehicle Standards and Dimensions; Mounting Hole Placement Specifications

6 SDD900-00
4 I N S TALL ATI O N
MAX.
300 mm
MAX.
400 mm
EN 1646-1EN 1645-1
420 mm 58 mm
76 mm
22 mm
10 mm
27 mm
57 mm
92 mm
127 mm
162 mm
231 mm
312 mm
332 mm
258 mm
436 mm (581 mm) (736 mm)
