Thümler Z3 - Page 20

20
Calibration Factor:
If you enter [0]”, you start a calibration program (see: “Change of the load cell”).
Maximum Force of the Machine:
When the amount of the force is exceeded, the machine is automatically switched off
and an emergency message is shown.
Return Speed: Return Speed is the speed for the Return key
(“Return home function”).
M V/V: 3.145
New:
Sensitivity of 3.145m V/V is selected
Here you have to enter the changed value from data sheet
and confirm with the [Return] key
Cal = 1.0
neu:
Calibration factor is 1.0
Here you have to enter the changed value
and confirm with the [Return] key
F limit H = 1999 N
New
Maximum force is 1999 N
(Maximum capacity of the load cell –1N)
Here you have to enter the changed value and confirm with the
[Return] key
VR = 500 mm/min
New
Return Speed is 500 mm/min
Here you have to enter the changed value and confirm with the
[Return] key
