Fitting Load Cell:
The Z-Beam type load cell is mounted under the moving crosshead. Your
machine will be provided with a load cell equal to or less than the maximum
capacity of the machine. Connect the load cell by plugging the 5 pin connector
into the load cell socket on the rear side of the machine.
Limits of the Load Cell:
Load Cell should not be deformed more than maximum 0.2 mm in both
directions.
When doing pressure tests, be sure that you do not bend a load cell to the
side. Using a low force load cell, there is a high risk of its damage by
permanent bending of the load cell which is due to its constructive principle. If
there is danger of the load cell overload, we recommend using special
protection equipment which we also provide
After overload, the load cell still shows measurements but they are not linear
anymore.
That is why we recommend using pneumatic grips for low force tests to avoid
an accidental destruction of the load cell when tightening the clamps.
To ensure the accuracy of the load cell, a calibration test should be done with
different weights.
If it is necessary, adjust also the calibration factor.
We can only provide the load cell function as guaranteed by the manufacture.
Any claims which are due to false fixing or overload are not accepted.
Zero Adjustment:
By pressing the [1] key before testing zero adjustment is done.
As the clamping of a specimen already produces force zero, adjustment
should be always done before each test.
