THUNDER TIGER SLEDGE HAMMER S50 Instruction Manual & Parts Catalogue

PD1774
FORWARD ONLY KIT, MTA4
單向前進套件組
PD1756
TITANIUM STEERING LINK ROD
鈦合金前轉向拉桿
PD1757
TITANIUM REAR LINK ROD
鈦合金後輪座拉桿
PD1762
OPTION STEERING KIT
伺服緩衝組套件
1165P
FUEL FILTER
濾油器
9713
TUNED PIPE .50
加速管
PD1301
SELF-LOCK NUT (BLUE)
止鬆螺帽零件包(藍)
PD1304
SELF-LOCK NUT (BLUE)
止鬆螺帽零件包(藍)
PD1761
ALUMINUM LOCK NUT/BLUE
止鬆螺帽（藍色）
9792-B 空氣濾清器組(黑)
AIR FILTER(BLACK) .50
9792-G 空氣濾清器組(綠)
AIR FILTER(GREEN) .50
9792-O 空氣濾清器組(橘)
AIR FILTER(ORANGE) .50
9792-W 空氣濾清器組(白)
AIR FILTER(WHITE) .50
9792-Y 空氣濾清器組(黃)
AIR FILTER(YELLOW) .50
PD1764
SERVO SAVER HUB/SPRING
轉向固定座/彈簧組
PD1765
OPTION STEERING HARDWARE
轉向墊片螺絲組
PD1763
OPTION STEERING RACK/ARM
轉向曲柄/搖臂組
PD1771
OPTION BRAKE DISC
OPT煞車片
OPTIONAL PARTS LIST 選購零件表
25
PD1583 JR轉向伺服機臂
STEERING SERVO SAVER,JR
PD1582 轉向伺服機臂
SERVO SAVER,HITECH
PD6337
STEERING BUSHING
緩衝搖臂軸套
PD7249
WHEEL HEX DRIVES,BLUE
六角輪轂轉換器
PN1527
MANIFOLD, .50 PIPE
排氣彎管組
PN1810
STEEL CLUTCH SET
鋼離合器組
PN1809
FLYWHEEL SET,STEEL CLUTCH
飛輪組,鋼片式
PN1808
CLUTCH BELL
離合器罩
PN1807
CLUTCH SPRING
離合器彈簧

THUNDER TIGER SLEDGE HAMMER S50 Specifications

Weight and Dimensions

overall length	615 mm / 24.2 in
overall height	273 mm / 10.7 in
overall width	438 mm / 17.2 in
wheelbase	368 mm / 14.5 in
max ground clearance	108 mm / 4.25 in
front track width	436 mm / 17.2 in
rear track width	436 mm / 17.2 in
weight (RTR)	6200 g / 13.76 lb
wheel diameter	174 mm / 6.85 in
