THUNDER TIGER TTR4550 User Manual

5
PARTS DRAWINGS
No.3014 Pull-Pull System
Clevis(2)
Threaded End(2)
2mm x 8mm
Screw(2)
Bass Tube(8)
2mm Hex Nut(2)
Z-Bend End(2)
Cable(1)
No.3015 Scale Tail Gear
Blind Nut(2, Installed in the Fuse.)
Tail Gear(1)
4mm x 20mm Sink Head Screw
Spring (2)
Control Horn(1)
E Clip(1)
Steering Shaft(1)
Steering Fork(1)
2.6mm x 26mm
Sink Head Screw(1)
Tire(1)
Tail Wheel(1)
Plastic Washer(2)
Wheel Spacer(1)
2.3mm x 12mm
Wood Screw(2)
No.3012 Anti Vibration Engine Mount
Mounting Beam(2)
TWasher(8)
Rubber(8)
Blind Nut(4)
5mmx40
Socket Screw(4)
Hex Wrench(1)
Spring Washer(4)
Eng Mounting Screw
6/32 x 20mm(4)
4mm x 20mm(4)
AS6154 Decal
AS6153 Piano Wire
Piano Wire(1)
No.3016 2.3mm Pushrod Set(Sold in Pair)
Dia 2.3mm(0.09") Pushrod (4)
Wire Guide(1)
2mm Hex Nut(4)
Clevis(4)
2mm x 8mm
Screw(4)
