41
VSM-de-171005
5.2 Survey Of Commands
Command Code
Type of Device TD
Product Name PN
Serial Number Device SD
Serial Number Head (Sensor) SH
Version Device VD
Version Firmware VF
Version Bootloader VB
Baud Rate BR
Response Delay RD
Device Restart DR
Measurement Range MR
Measurement Value MV
Measurement Value 1 (Pirani) M1
Measurement Value 4 (Cold Cathode) M4
Relay 1 R1
Relay 2 R2
Adjust High (Atmosphere Pressure) AH
Adjust Low (Zero Pressure) AL
Sensor Transition ST
Cathode Control CC
Gas Correction Factor 1 (Pirani) C1
Gas Correction Factor 4 (Cold Cathode) C4
Analog Output Characteristic OC
1) Valid only for transducers with LCD display
2) Not available when cold cathode is switched off
The previous communication protocol version V1 will further-
more be supported by all Smartline devices! Therefore all tele-
grams built according to protocol version 1 can further be used.
