APPENDIX
Description Parameter Unit Setting range
IN8
Logic
Active-ON | Active-OFF
IN8 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN8 tOFF
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN8 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Binary input IN9
IN9
Logic
Active-ON | Active-OFF
IN9 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN9 tOFF
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN9 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Binary input IN10
IN10
Logic
Active-ON | Active-OFF
IN10 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN10 tOFF
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN10 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Binary input IN11
IN11
Logic
Active-ON | Active-OFF
IN11 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN11 tOFF
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN11 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Binary input IN12
IN12
Logic
Active-ON | Active-OFF
IN12 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
