APPENDIX
Description Parameter Unit Setting range
IN16 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Binary input IN17
IN17
Logic
Active-ON | Active-OFF
IN17 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN17 tOFF
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN17 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Binary input IN18
IN18
Logic
Active-ON | Active-OFF
IN18 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN18 tOFF
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN18 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Binary input IN19
IN19
Logic
Active-ON | Active-OFF
IN19 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN19 tOFF
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN19 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Binary input IN20
IN20
Logic
Active-ON | Active-OFF
IN20 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN20 tOFF
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN20 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Binary input IN21
