APPENDIX
Description Parameter Unit Setting range
IN21
Logic
Active-ON | Active-OFF
IN21 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN21 tOFF
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN21 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Binary input IN22
IN22
Logic
Active-ON | Active-OFF
IN22 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN22 tOFF
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN22 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Binary input IN23
IN23
Logic
Active-ON | Active-OFF
IN23 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN23 tOFF
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN23 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Binary input IN24
IN24
Logic
Active-ON | Active-OFF
IN24 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN24 tOFF
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN24 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Binary input IN25
IN25
Logic
Active-ON | Active-OFF
IN25 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
