APPENDIX
Description Parameter Unit Setting range
IN34
Logic
Active-ON | Active-OFF
IN34 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN34 tOFF
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN34 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Binary input IN35
IN35
Logic
Active-ON | Active-OFF
IN35 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN35 tOFF
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN35 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Binary input IN36
IN36
Logic
Active-ON | Active-OFF
IN36 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN36 tOFF
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN36 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Binary input IN37
IN37
Logic
Active-ON | Active-OFF
IN37 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN37 tOFF
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN37 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Binary input IN38
IN38
Logic
Active-ON | Active-OFF
IN38 tON
Value
s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
