Thytronic NA11 - Page 163

163
NA11 - Manual - 02 - 2009
APPENDIX
Description Parameter Unit Setting range
IN42 matching
Reset LEDs | Set profi le | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2
| Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | 79 Enable | 79 Block | None
Relays
K1
Logic
De-energized | Energized
Operation MODE
No-latched | Pulse | Latched
Minimum pulse width
ms 0 ... 500 step = 5
K2
Logic
De-energized | Energized
Operation MODE
No-latched | Pulse | Latched
Minimum pulse width
ms 0 ... 500 step = 5
K3
Logic
De-energized | Energized
Operation MODE
No-latched | Pulse | Latched
Minimum pulse width
ms 0 ... 500 step = 5
K4
Logic
De-energized | Energized
Operation MODE
No-latched | Pulse | Latched
Minimum pulse width
ms 0 ... 500 step = 5
K5
Logic
De-energized | Energized
Operation MODE
No-latched | Pulse | Latched
Minimum pulse width
ms 0 ... 500 step = 5
K6
Logic
De-energized | Energized
Operation MODE
No-latched | Pulse | Latched
Minimum pulse width
ms 0 ... 500 step = 5
K7
Logic
De-energized | Energized
Operation MODE
No-latched | Pulse | Latched
Minimum pulse width
ms 0 ... 500 step = 5
K8
Logic
De-energized | Energized
Operation MODE
No-latched | Pulse | Latched
Minimum pulse width
ms 0 ... 500 step = 5
K9
Logic
De-energized | Energized
Operation MODE
No-latched | Pulse | Latched
Minimum pulse width
ms 0 ... 500 step = 5
K10
Logic
De-energized | Energized
Operation MODE
No-latched | Pulse | Latched
Minimum pulse width
ms 0 ... 500 step = 5
LEDs
START
Type
No-latched | Latched
TRIP
Type
No-latched | Latched
L1
Type
No-latched | Latched
L2
