NA11 - Manual - 02 - 2009
APPENDIX
Description Parameter Unit Setting range
Type No-latched | Latched
L3
Type
No-latched | Latched
L4
Type
No-latched | Latched
L5
Type
No-latched | Latched
L6
Type
No-latched | Latched
L7
Type
No-latched | Latched
L8
Type
No-latched | Latched
L9
Type
No-latched | Latched
L10
Type
No-latched | Latched
Analog outputs
Current loop 1
Loop 1 Measure assigned Loop1-Mis
Frequency | IL1 | IL2 | IL3 | IE | IL | PLC | None
Loop 1 Output range Loop1-Range
0-2 mA | 0-4 mA | 0-5 mA | 1-5 mA | 0-6 mA | 1-6
mA | 0-10 mA | 4-20 mA
Loop 1 Sign Loop1-Sign
Unipolar | Bipolar
Loop 1 Nominal multiplier Loop1-M
0.01 ... 100.00 step = 0.01
Current loop 2
Loop 2 Measure assigned Loop2-Mis
Frequency | IL1 | IL2 | IL3 | IE | IL | PLC | None
Loop 2 Output range Loop2-Range
0-2 mA | 0-4 mA | 0-5 mA | 1-5 mA | 0-6 mA | 1-6
mA | 0-10 mA | 4-20 mA
Loop 2 Sign Loop2-Sign
Unipolar | Bipolar
Loop 2 Nominal multiplier Loop2-M
0.01 ... 100.00 step = 0.01
Current loop 3
Loop 3 Measure assigned Loop3-Mis
Frequency | IL1 | IL2 | IL3 | IE | IL | PLC | None
Loop 3 Output range Loop3-Range
0-2 mA | 0-4 mA | 0-5 mA | 1-5 mA | 0-6 mA | 1-6
mA | 0-10 mA | 4-20 mA
Loop 3 Sign Loop3-Sign
Unipolar | Bipolar
Loop 3 Nominal multiplier Loop3-M
0.01 ... 100.00 step = 0.01
Current loop 4
Loop 4 Measure assigned Loop4-Mis
Frequency | IL1 | IL2 | IL3 | IE | IL | PLC | None
Loop 4 Output range Loop4-Range
0-2 mA | 0-4 mA | 0-5 mA | 1-5 mA | 0-6 mA | 1-6
mA | 0-10 mA | 4-20 mA
Loop 4 Sign Loop4-Sign
Unipolar | Bipolar
Loop 4 Nominal multiplier Loop4-M
0.01 ... 100.00 step = 0.01
Self-test Relay
MINOR Fail alarm
NO | YES
Self-test relay
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
MMI
Display modules
Assigned modules | All modules
Auto-reclose - 79
79 Enable 79 Enable
OFF | ON
79 Function mode 79 Mode
Rapid | Rapid+Slow
Number of delayed reclosures N.DAR
0 ... 5 step = 1
Rapid reclosure dead time trdt s
0.1 ... 19.9 step = 0.1
20 ... 60 step = 1
Slow reclosure dead time tsdt s 1 ... 200 step = 1
Recalim time
