Thytronic NA11 - Page 165

165
NA11 - Manual - 02 - 2009
APPENDIX
Description Parameter Unit Setting range
Value s 1 ... 200 step = 1
Slow reclosure fault discrimination time td1 s 0 ... 10 step = 1
Delayed reclosure fault discrimination time td2 s 0 ... 10 step = 1
Manual close (only R+S) fault discrimination time set MC-td-EN
OFF | ON
Manual close fault discrimination time td s 1 ... 10 step = 1
Reset cycle from manual open MO-RES
OFF | ON
79-I> Start 79-I>
OFF | ON
79-I>> Start 79-I>>
OFF | ON
79-I>>> Start 79-I>>>
OFF | ON
79-IE> Start 79-IE>
OFF | ON
79-IE>> Start 79-IE>>
OFF | ON
79-IE>>> Start 79-IE>>>
OFF | ON
Relays cycle in progress 79-Run-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Relays reclosure 79-AR-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Relays reclosure fail 79-Fail-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
LEDs cycle in progress 79-Run-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
LEDs reclosure 79-AR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
LEDs reclosure fail 79-Fail-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
Profi le selection
Active profi le
A | B | By INPUT
Profi le A
Thermal protection with RTD thermometric probes - 26
PT1 Probe
ThAL1 Alarm
ThAL1 Enable ThAL1 Enable
OFF | ON
26 PT1 Alarm threshold ThAL1 ^C 0 ... 200 step = 1
ThAL1 Operating time
Value
s 0 ... 100 step = 1
ThAL1 Alarm relays ThAL1-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
ThAL1 Alarm LEDs ThAL1-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
Th>1 Trip
Th>1 Enable Th>1 Enable
OFF | ON
26 PT1 Trip threshold Th>1 ^C 0 ... 200 step = 1
Th>1 Operating time
Value
s 0 ... 100 step = 1
Th>1 Breaker failure Th>1BF
OFF | ON
Th>1 Trip relays Th>1-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Th>1 Trip LEDs Th>1-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
PT2 Probe
ThAL2 Alarm
ThAL2 Enable ThAL2 Enable
OFF | ON
26 PT2 Alarm threshold ThAL2 ^C 0 ... 200 step = 1
ThAL2 Operating time
Value
s 0 ... 100 step = 1
ThAL2 Alarm relays ThAL2-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
ThAL2 Alarm LEDs ThAL2-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
Th>2 Trip
Th>2 Enable Th>2 Enable
OFF | ON
26 PT2 Trip threshold Th>2 ^C 0 ... 200 step = 1
Th>2 Operating time
