Controls and Equipment
CASPIAN
™
MODEL CHP
EQUIPMENT COMPARTMENT
1. Silent Flo 5000
®
circulation pump
2. Wavemaster
®
jet pump
3. No-Fault
®
heater
4. IQ 2020
®
spa control box
5. Main drain valve
6. Secondary drain
7. Ozone injector (optional accessory)
8. Bonding terminal
2
3
4
7
6
5
OVERHEAD VIEWS
A. Hydromassage jet with
directional nozzle
B. Hydromassage jet with dual port
rotary nozzle
C. Precision
®
jets
D. Heater return and spa drain
E. Secondary suction
F. Light lens
G. Spa pillow
H. Filter compartment
I. Control panel
J. Comfort Control
®
lever for
Precision jets
K.Cupholder
L. Water Feature lever
M. Water Feature
B
B
A
A
A
A
E
F
G
K
J
I
H
D
C
C
C
C
G
1
2
K
L
E
E
CONTROLS AND EQUIPMENT
M
K
8
K
