Tiger TI-01SS - Main Technical Index

1
THANKS FOR USING OUR EQUIPMENT,PLEASE READ THIS MANUAL CAREFULLY BEFORE
USAGE.PREFACE THE PRODUCTS ARE SERIES TOP GRADE FULL STAINLESS STEEL
ELECTRONIC WEIGHING INDICATOR AND STAINLESS STEEL WATERPROOF PLATFORM
SCALE, WE USED THE LATEST HIGH-TECH, IT HAS THE CHARACTERISTIC OF HIGH
PRECISION, DISPLAY CELERITY, DURABLE, BEST AFTER SALE SERVICES, GOOD
CORROSION-PROOF. VARIOUS MEASURES ADOPTED TO ENSURE IT‟ S EXCELLENT
WATERPROOF AND DAMPPROOF.IT IS WIDELY USED FOR NOT ONLY RETAIL STORES,
RATION PACKING BUT ALSO FOR HIGH HUMIDITY SURROUNDING OF FOOD AND SEAFOOD
PACKING. WE HAD GET SEVERAL NATIONAL PATENTS FOR THE PRODUCTS.
1 MAIN TECHNICAL INDEX
1.1 BASIC DATA OF XK3101SS STAINLESS STEEL INDICATOR：
ITEM
LITHIUM BATTERY VERSION
LEAD-ACID BATTERY VERSION
WATERPROOF AND
DUSTPROOF GRADE
IP68
OVERALL DIMENSION（W X T X
H）
254×86×170 mm
ACCURACY OF INDICATOR
3000~30000
HEIGHT OF WEIGHING LED “8”
36mm
HEIGHT OF WEIGHING LCD “8”
43mm
ZERO RANGE
±4%
TARE RANGE
100%
RECHARGEABLE BATTERY
5V/4000mAH LITHIUM BATTERY
6V/4500mAH LEAD-ACID
BATTERY
TRANSFORMER
5V/2A ELECTRONIC
100~240V/50~60Hz
9V/1A ELECTRONIC
100~240V/50~60Hz
T TYPE FRAME ASSEMBLY
OPTIONAL ASSEMBLY， FOR INSTALL 38mm POLE，INCLUDES
STAINLESS STEEL T TYPE FRAME 1PC，STAINLESS STEEL TUBE
SUPPORT 1PC，M6×8 JACKSCREW 2PCS，L TYPE SMALL WRENCH
1PC，M4×8 STAINLESS STEEL SCREW 4PCS
232 INTERFACE
OPTIONAL
485 INTERFACE
OPTIONAL
1.2 BASIC DATA OF FULL STAINLESS STEEL PLATFORM：
PLATE SIZE
2828cm
3040cm
4050cm
5060cm
6080cm
WATERPROOF AND
DUSTPROOF GRADE
IP68
CAPACITY
15/30/60kg
30/60/150kg
60/150/300kg
60/150/300kg
150/300/600kg
LOAD CELL SIZE (mm)
150×35×40
150×44×40
150×60×62
150×60×62
150×90×74
SIDE HOLE
1.3 WORKING TEMPERATURE：-5~+35℃
1.4 STORAGE TEMPERATURE：-25~50℃
