TiLite ZR - Removing

4-6
ZR Owner’s Manual
OM_ZR_0913RevA
CHAPTER 4: BACKRESTS And PUSH HAndLES
“Top View”
Figure 4-9
Adjustable Height Push Handles
Figure 4-10
Adjustable Height Push Handles
Allen
Screws
Quick Release
Cam Lock
Clamp
Push Handle
Removing
Tools Needed:
• 3/16” Allen Wrench
1. Remove the four Allen screws. See Figure 4-10.
2. Remove the clamp and cam lock.
