1
1. Main Technical Characteristics 3
2. Safety Measures 4
3. Construction and Description of the Main Units of the Heater 4
4. Possible Heater Faults, their Root Causes & Troubleshooting Methods 4
Possible Faults & Replacement of Parts in the Timberline Heating System Components 5
5. Repair, and Replacement of Pre-heater Units 8
5.1 Replacement of the Glow Plug 9
5.2 Replacement of the Plug Screen 10
5.3 Replacement of the Flame Detector 11
5.4 Replacement of the Air Blower 13
5.5 Replacement of the Control Unit 14
5.6 Replacement of Temperature Sensors 15
5.7 Replacement of the Combustion Chamber 16
5.8 Replacement of the Fuel Pump 17
5.9 Replacement of the Pump 19
6. Domestic Water Heat Exchanger 20
7. Air Sensor 20
8. Water Solenoid Valve 21
9. Heating Fans 21
10. Timberline Tank 22
11. Pinout and Replacement of the Control Box 23
12. Touch Panel 24
13. Purging the System 24
14. Pre-heater Check after Installation 25
15. Manufacturer’s Warranty 25
Warranty Part Replacement Labor Time 26
Contents
