1. Main Technical Characteristics
See Table 1 for the main technical characteristics of the pre-heater.
The technical characteristics include a ±10% tolerance and are specied for
operation at the rated power supply voltage and air temperature
of 68°F.
Table 1.
Parameter description
Model
Binar-5B-Compact Binar-5D-Compact
Heat capacity, BTU 17,060
Rated power voltage, V 12
Operating power voltage
range, V
9.5 - 16
Fuel type Gasoline Diesel
Fuel consumption (max.), GPH 0.18 0.21
Heat transfer agent DEX-Cool Antifreeze
Electric power consumed,
pump included, (max.), W
45 45
Power consumed at startup
(100 s), W
65 65
Maximum liquid heating tem-
perature, °F
+194
Ignition mode Manual or Automatic
Preheater weight in full con-
guration, lbs, max.
19.8
