1.1 . B
ASIC WORKING PRINCIPLE
TV300 uses piezoelectric acceleration transducer to convert vibration signal into electric
signal. Then by analyzing input signal, results including RMS of velocity values, peak-
peak value of displacement, peak values of acceleration or real-time spectral charts are
displayed or printed out.
1.2. APPLICATION RANGE
The vibration meter is designed to test conventional vibration, especially the vibration
test in rotating and reciprocating machines. It can be used not only to test the
acceleration, velocity, and displacement of vibration as well as rev (or inherent
frequency), but also perform simple failure diagnosis.
The technical specifications of TV300 comply with the requirements of GB 13823.3.
TV300 is widely used in machinery, power, metallurgy, automobile and other industrial
fields.
1.3. TECHNICAL SPECIFICATIONS
- Measurement range
Acceleration: 0.1 m/s2- 392 m/s2 (Peak)
Velocity: 0.01 - 80 cm/s (RMS)
Displacement: 0.001 - 10 mm (Peak - peak)
- The frequency range
Acceleration: 10Hz - 200 Hz, 10Hz - 500 Hz, 10Hz - 1KHz, 10Hz - 10KHz
Velocity: 10Hz - 1KHz
Displacement: 10Hz- 500 Hz
- Accuracy: <
±5%
- Temperature range: 0°C ~ 40°C
- Humidity range: <
80%
1.4. BASIC CONFIGURATION AND OPTIONAL ACCESSORIES
- Basic configuration
Title Quantity
TV300 main body 1
6V/800mA ~220V/50Hz power adapters 1 (select one of them)
6V/800mA ~110V/50Hz power adapters
Vibration transducer TSV-01 1
Leather wrap 1
Package case 1
Manual 1
- Optional accessories
Title Quantity
Data Management software(with a cable) 1
Printer(with a cable) 1
Magnetic base 1
Probe groupware 1
Long needle 1
