Time TV-300 - Appearance; Description of Main Body

3.2. APPEARANCE
Figure 3-2
3.3. D
ESCRIPTION OF MAIN BODY
Title
1 Display screen 1
2 Front cover 1
3 LCD 1
4 Keyboard 16
5 Sealed tray 1
6 Plastic frame 1
7 Front PCB 1
8 Back PCB 1
9 Back cover 1
10 Hole cover 2
11 Bolt M3 4
12 Li battery 1
13 Battery holder 1
14 Gasket M2 2
15 Bolt M2 19
6 Manual TV-300
Nameplate
A sensitivity
knob- in the
hole
Display
window
Charging indicate light
RS232 socket
Charging socket
Transducer socket
Keyboard
